BDP949

Type Designator: BDP949

Material of Transistor: Si

Polarity: NPN

Maximum Collector Power Dissipation (Pc): 3 W

Maximum Collector-Base Voltage |Vcb|: 65 V

Maximum Collector-Emitter Voltage |Vce|: 60 V

Maximum Emitter-Base Voltage |Veb|: 5 V

Maximum Collector Current |Ic max|: 3 A

Max. Operating Junction Temperature (Tj): 150 °C

Transition Frequency (ft): 100 MHz

Collector Capacitance (Cc): 40 pF

Forward Current Transfer Ratio (hFE), MIN: 25

Noise Figure, dB: -

Package: SOT323
