BF479S TO-51 50MA 25V 0.17W PNP TRANSISTOR
0 - Yorum
Kategori
Kalan Adet
4183 Adet
Fiyat
0,14 USD + KDV
*0,54 TL den başlayan taksitlerle!
5,78 TL
BF479S TO-51 50MA 25V 0.17W PNP TRANSISTOR
BF479S
Type Designator: BF479S
Material of Transistor: Si
Polarity: PNP
Maximum Collector Power Dissipation (Pc): 0.17 W
Maximum Collector-Base Voltage |Vcb|: 30 V
Maximum Collector-Emitter Voltage |Vce|: 25 V
Maximum Emitter-Base Voltage |Veb|: 3 V
Maximum Collector Current |Ic max|: 0.05 A
Max. Operating Junction Temperature (Tj): 150 °C
Transition Frequency (ft): 700 MHz
Collector Capacitance (Cc): 0.5 pF
Forward Current Transfer Ratio (hFE), MIN: 20
Package: TO51
