BC856W SOT-323 0.1A 65V 0.2W PNP TRANSISTOR
0 - Yorum
Kategori
Kalan Adet
15 Adet
Fiyat
0,12 USD + KDV
*0,46 TL den başlayan taksitlerle!
4,97 TL
BC856W SOT-323 0.1A 65V 0.2W PNP TRANSISTOR - ONLİNE ÖZEL FİYAT
BC856W
Type Designator: BC856W
SMD Transistor Code: 3D-_3Dt_3DW
Material of Transistor: Si
Polarity: PNP
Maximum Collector Power Dissipation (Pc): 0.2 W
Maximum Collector-Base Voltage |Vcb|: 80 V
Maximum Collector-Emitter Voltage |Vce|: 65 V
Maximum Emitter-Base Voltage |Veb|: 5 V
Maximum Collector Current |Ic max|: 0.1 A
Max. Operating Junction Temperature (Tj): 150 °C
Transition Frequency (ft): 100 MHz
Collector Capacitance (Cc): 3 pF
Forward Current Transfer Ratio (hFE), MIN: 125
Package: SOT323
Bu ürüne ilk yorumu siz yapın!
