AO4604 SOP-8 6.9A 30V MOSFET
0 - Yorum
Kategori
Kalan Adet
27 Adet
Fiyat
0,78 USD + KDV
*3,00 TL den başlayan taksitlerle!
32,30 TL
AO4604 MOSFET. Datasheet pdf. Equivalent
Type Designator: AO4604
Marking Code: 4604
Type of Transistor: MOSFET
Type of Control Channel: NP -Channel
Maximum Power Dissipation (Pd): 2 W
Maximum Drain-Source Voltage |Vds|: 30 V
Maximum Gate-Source Voltage |Vgs|: 20 V
Maximum Drain Current |Id|: 6.9(5) A
Maximum Junction Temperature (Tj): 150 °C
Maximum Drain-Source On-State Resistance (Rds): 0.028(0.052) Ohm
Package: SOP8
