2SC2782 XM5 500V 20A 220W NPN TRANSISTOR
0 - Yorum
Kategori
Kalan Adet
1 Adet
Fiyat
56,00 USD + KDV
*215,63 TL den başlayan taksitlerle!
2.319,17 TL
2SC2782 XM5 500V 20A 220W NPN TRANSISTOR
2SC2782
Type Designator: 2SC2782
Material of Transistor: Si
Polarity: NPN
Maximum Collector Power Dissipation (Pc): 220 W
Maximum Collector-Base Voltage |Vcb|: 36 V
Maximum Emitter-Base Voltage |Veb|: 4 V
Maximum Collector Current |Ic max|: 20 A
Max. Operating Junction Temperature (Tj): 175 °C
Transition Frequency (ft): 175 MHz
Forward Current Transfer Ratio (hFE), MIN: 70
Package: XM5
