2SA429 TO-92 0.03A 150V 0.15W PNP TRANSISTOR
2SA429
Type Designator: 2SA429
Material of Transistor: Si
Polarity: PNP
Maximum Collector Power Dissipation (Pc): 0.15 W
Maximum Collector-Base Voltage |Vcb|: 150 V
Maximum Collector-Emitter Voltage |Vce|: 150 V
Maximum Emitter-Base Voltage |Veb|: 3 V
Maximum Collector Current |Ic max|: 0.03 A
Max. Operating Junction Temperature (Tj): 75 °C
Transition Frequency (ft): 40 MHz
Collector Capacitance (Cc): 7 pF
Forward Current Transfer Ratio (hFE), MIN: 60
Package: TO92
